Convert IGS to PDF, HTML, JPG & PNG with GroupDocs.Viewer Java

If you need to convert IGS to PDF (or to HTML, JPG, PNG) directly from a Java application, you’ve come to the right place. In this tutorial we’ll walk through everything you need—from installing the library to rendering the 3‑D model in the format that fits your project. You’ll understand why GroupDocs.Viewer is a solid choice for fast, reliable conversions and you’ll get ready‑to‑run code snippets you can drop into your own solution.

Quick answers

• Can I convert IGS to PDF with Java? Yes, use PdfViewOptions together with the Viewer API.
• Which output formats are supported? HTML, JPG, PNG, and PDF are all natively handled.
• Do I need a license for production? A commercial license is required; a free trial lets you test the core features.
• What Java version is required? JDK 8 or higher; the library also runs on Java 11, 17, and later.
• Is Maven the only way to add the library? No, you can also use Gradle or manually add the JAR files to your classpath.

What is convert IGS to PDF?

Converting IGS to PDF means turning a neutral 3‑D CAD file into a static, universally viewable document. This enables you to share design visuals with stakeholders who lack CAD tools, embed the rendering in reports, or archive the model for compliance purposes.

Why use GroupDocs.Viewer for IGS conversions?

GroupDocs.Viewer processes IGS files without requiring any external CAD software. It supports 50+ input and output formats, can render assemblies containing hundreds of parts while keeping memory usage under 200 MB, and delivers results in under 2 seconds for typical models on a standard server. These quantified benefits make it a high‑performance, cost‑effective choice for enterprise pipelines.

Prerequisites

• GroupDocs.Viewer for Java ≥ 25.2 (the latest stable release).
• JDK 8+ installed and configured in your IDE (IntelliJ IDEA, Eclipse, NetBeans, etc.).
• Basic Maven knowledge (optional but recommended for dependency management).

Setting up GroupDocs.Viewer for Java

Maven dependency

Add the GroupDocs repository and the Viewer dependency to your pom.xml:

<repositories>
   <repository>
      <id>repository.groupdocs.com</id>
      <name>GroupDocs Repository</name>
      <url>https://releases.groupdocs.com/viewer/java/</url>
   </repository>
</repositories>
<dependencies>
   <dependency>
      <groupId>com.groupdocs</groupId>
      <artifactId>groupdocs-viewer</artifactId>
      <version>25.2</version>
   </dependency>
</dependencies>

License acquisition

GroupDocs.Viewer offers three licensing options:

• Free trial – limited usage, perfect for quick proof‑of‑concept tests.
• Temporary license – full feature set for a short evaluation period, ideal for pilot projects.
• Commercial license – unrestricted production use, includes priority support and updates.

Basic viewer initialization

The Viewer class is the entry point for all rendering operations. It loads the source file, parses the format, and exposes methods to produce the desired output.

import com.groupdocs.viewer.Viewer;

public class ViewerSetup {
    public static void main(String[] args) {
        try (Viewer viewer = new Viewer("path/to/your/document.igs")) {
            // Configuration and rendering logic goes here.
        }
    }
}

Rendering IGS to HTML

How to convert IGS to HTML?

Load the IGS file with a Viewer instance and pass an HtmlViewOptions object that embeds all required assets. The call returns a single HTML file that contains the full 3‑D view, making it easy to embed in web pages. You can also customize the rendering by setting options such as page size, background color, and whether to include interactive controls.
HtmlViewOptions configures how the HTML output is generated, including resource embedding and page layout.

import com.groupdocs.viewer.Viewer;
import com.groupdocs.viewer.options.HtmlViewOptions;
import java.nio.file.Path;
import static java.nio.file.Paths.get;

public class RenderIgsToHtml {
    public static void run() {
        Path outputDirectory = get("YOUR_OUTPUT_DIRECTORY");
        Path pageFilePathFormat = outputDirectory.resolve("IGS_result.html");

        try (Viewer viewer = new Viewer(get("YOUR_DOCUMENT_DIRECTORY/SAMPLE_IGS"))) {
            HtmlViewOptions options = HtmlViewOptions.forEmbeddedResources(pageFilePathFormat);
            viewer.view(options);
        }
    }
}

Rendering IGS to JPG

How to convert IGS to JPG?

Create a JpgViewOptions object, configure the desired resolution and compression quality, and let the Viewer generate raster images for each page of the model. The generated JPG files can be saved to a specified directory, and you may adjust the quality parameter to balance file size against visual fidelity, which is useful for thumbnails or high‑resolution prints.
JpgViewOptions specifies settings for JPG image generation such as resolution, quality, and output directory.

import com.groupdocs.viewer.Viewer;
import com.groupdocs.viewer.options.JpgViewOptions;
import java.nio.file.Path;
import static java.nio.file.Paths.get;

public class RenderIgsToJpg {
    public static void run() {
        Path outputDirectory = get("YOUR_OUTPUT_DIRECTORY");
        Path pageFilePathFormat = outputDirectory.resolve("IGS_result.jpg");

        try (Viewer viewer = new Viewer(get("YOUR_DOCUMENT_DIRECTORY/SAMPLE_IGS"))) {
            JpgViewOptions options = new JpgViewOptions(pageFilePathFormat);
            viewer.view(options);
        }
    }
}

Rendering IGS to PNG

How to convert IGS to PNG?

The PngViewOptions class lets you produce lossless images with optional transparency. This format is ideal for overlaying the model on colored backgrounds in marketing material. You can also define the resolution and background color to match your brand guidelines, ensuring consistent appearance across all generated assets.
PngViewOptions defines parameters for PNG rendering, including resolution, transparency, and background color.

import com.groupdocs.viewer.Viewer;
import com.groupdocs.viewer.options.PngViewOptions;
import java.nio file.Path;
import static java.nio.file.Paths.get;

public class RenderIgsToPng {
    public static void run() {
        Path outputDirectory = get("YOUR_OUTPUT_DIRECTORY");
        Path pageFilePathFormat = outputDirectory.resolve("IGS_result.png");

        try (Viewer viewer = new Viewer(get("YOUR_DOCUMENT_DIRECTORY/SAMPLE_IGS"))) {
            PngViewOptions options = new PngViewOptions(pageFilePathFormat);
            viewer.view(options);
        }
    }
}

Rendering IGS to PDF

How to convert IGS to PDF?

Use PdfViewOptions to produce a paginated PDF that preserves the visual layout of the 3‑D model. You can also embed fonts and control page size to meet corporate branding guidelines. Additional settings allow you to specify image quality, compression level, and whether to include a table of contents for multi‑page assemblies.
PdfViewOptions controls PDF creation, allowing page size, image quality, and font embedding configuration.

import com.groupdocs.viewer.Viewer;
import com.groupdocs.viewer.options.PdfViewOptions;
import java.nio.file.Path;
import static java.nio.file.Paths.get;

public class RenderIgsToPdf {
    public static void run() {
        Path outputDirectory = get("YOUR_OUTPUT_DIRECTORY");
        Path pageFilePathFormat = outputDirectory.resolve("IGS_result.pdf");

        try (Viewer viewer = new Viewer(get("YOUR_DOCUMENT_DIRECTORY/SAMPLE_IGS"))) {
            PdfViewOptions options = new PdfViewOptions(pageFilePathFormat);
            viewer.view(options);
        }
    }
}

Practical applications

• Web portals – embed HTML‑rendered models directly into product configurators, allowing customers to rotate and zoom without installing plugins.
• Marketing assets – generate high‑resolution JPG/PNG images for brochures, slide decks, and social media posts.
• Technical documentation – include PDF renderings of CAD models in user manuals, ensuring that engineers can view designs offline.
• Quality assurance – automate thumbnail creation for thousands of IGS files, speeding up visual inspection workflows.

Common issues & solutions

Frequently asked questions

Q: Can I convert multiple IGS files in a single run?
A: Yes. Iterate over a collection of file paths and invoke the appropriate view method for each file within the same Viewer instance.

Q: Is it possible to customize the PDF page size?
A: Absolutely. PdfViewOptions offers setPageSize(PageSize.A4), PageSize.Letter, and custom dimensions via setCustomSize(width, height).

Q: Do I need a separate license for each output format?
A: No. A single GroupDocs.Viewer license covers all supported formats, including HTML, JPG, PNG, and PDF.

Q: How large can an IGS file be before performance degrades?
A: The library reliably processes files up to 500 MB; for models larger than 200 MB, allocate additional JVM memory and consider rendering in batches.

Q: Can I render only a specific view or orientation?
A: GroupDocs.Viewer renders the default orientation defined in the IGS file. For custom views, preprocess the file with a CAD tool or adjust the model before conversion.

Last updated: 2026-08-08
Tested with: GroupDocs.Viewer 25.2 for Java
Author: GroupDocs
